MANHATTAN XS expanded metal
With its unique elegance, it gives buildings their personal look.
Its large, easy to work mesh defines the volumes without weighing them down, the overall effect is almost evanescent, while guaranteeing the correct balance between transparency and light. A more narrow version of the original Manhattan.
| Maglia Mesh DL LWD | Thickness | Total Thickness | Dimension Hmax//LWD | Weight  | Weight  | Open Area | Max Open Area | Send inquiry |
|---|---|---|---|---|---|---|---|---|
| [mm] | [mm] | [mm] | [mm] | [Kg/m2] | [Kg/m2] | [%] | [%] | |
| 250 | 1,5 | ~ 33 | 3000 | 1,8 | 5,4 | 64 | 86 | |
| 250 | 2 | ~ 33 | 3000 | 2,5 | 7,2 | 64 | 86 | |
| 250 | 3 | ~ 33 | 3000 | 3 | 10,7 | 64 | 86 |
Aluminium Mild Steel, Galvanized Steel; Stainless Steel
Manhattan XS expanded metal Technical data sheet 1,03 MB (2 pages)
Expanded metal brochure 2,8 MB (68 pages)
Install a shading means using an item that gives the possibility of shielding all or part of the passage of sunlight while allowing the passage of air. Expanded metal is by nature a material that contains these two features, while having the advantage of being able to add an aesthetic and architectural value to each application.
Fixing & Mounting options
The fixing systems provide a variety of solutions for understructures and framing, making the expanded metal ready for installation.
Select from among the different types of understructures for the mounting of expanded metal.
