Made in Italy
MANHATTAN XL expanded metal
| Maglia Mesh DL LWD | Thickness | Total Thickness | Dimension Hmax//LWD | Weight  | Weight  | Open Area | Max Open Area | Send inquiry |
|---|---|---|---|---|---|---|---|---|
| [mm] | [mm] | [mm] | [mm] | [Kg/m2] | [Kg/m2] | [%] | [%] | |
| 250 | 1,5 | ~ 39 | 3000 | 2,7 | 7,9 | 41 | 78 | |
| 250 | 2,00 | ~ 39 | 3000 | 3,6 | 10,5 | 41 | 78 | |
| 250 | 3,00 | ~ 39 | 3000 | 5,4 | 15,7 | 41 | 78 |
Aluminium Mild Steel, Galvanized Steel; Stainless Steel
Manhattan XL expanded metal Technical data sheet 0,34 MB (2 pages)
Expanded metal brochure 2,8 MB (68 pages)
Install a shading means using an item that gives the possibility of shielding all or part of the passage of sunlight while allowing the passage of air. Expanded metal is by nature a material that contains these two features, while having the advantage of being able to add an aesthetic and architectural value to each application.
Fixing & Mounting options
The fixing systems provide a variety of solutions for understructures and framing, making the expanded metal ready for installation.
Select from among the different types of understructures for the mounting of expanded metal.
